Coating drying capacity and maximum spray rate calculator
How much water your inlet air can actually carry away, and the spray rate that supports.
- Runs in the browserNothing is submitted anywhere
- Working shownCheck every line by hand
- Plant figuresThe bands our grades run in
- Free, no sign-inNo account, no email
Written by the Rglax Pharma technical team, who formulate and manufacture every grade named on this calculator at our WHO-GMP works in Tahliwal, Una (drug manufacturing licence NNZ/23/238). Reviewed 3 September 2026. Licences and certificates.
Result
Drying capacity
479 g/min of water
- Ambient moisture
- 11.85 g/kgWater already in the air
- Exhaust moisture
- 28.34 g/kgWhat the air can hold on the way out
- Dry air mass flow
- 1,743 kg/h
- Maximum spray rate
- 563 g/minDispersion, at the solids above
How this was worked out
- inlet humidity ratio = 0.622 × pv ÷ (101.325 − pv) at 25 °C, 60% RH = 11.85 g/kg
- exhaust humidity ratio at 40 °C, 60% RH = 28.34 g/kg
- dry air mass = 1,500 m³/h × 1.162 kg/m³ = 1,743 kg/h
- capacity = 1,743 kg/h × 16.48 g/kg ÷ 60 = 479 g/min
- max spray = capacity ÷ (1 − 15 ÷ 100) = 563 g/min
Formula
saturation pressure, Antoine: log10 P = 8.07131 − 1730.63 ÷ (233.426 + T) humidity ratio W = 0.622 × Pv ÷ (P − Pv) drying capacity = dry air mass flow × (W exhaust − W ambient)
Why this number matters
This is the calculation that explains why a coating process that ran perfectly in February fails in July. The air can only carry away the difference between what it already holds and what it can hold at the exhaust condition. On a humid day that difference collapses, the bed stops drying at the spray rate you have always used, and you get picking and sticking on a formulation nothing has changed about.
Where it goes wrong
Treat the answer as a ceiling, not a setpoint. Run at 70 to 80 percent of it. And check it against the worst ambient humidity your site sees rather than today, because the process has to hold through the monsoon.
Worked example
With air volume of 1500 m³/h, ambient temperature of 25 °C, ambient humidity of 60 % RH, exhaust temperature of 40 °C, exhaust humidity of 60 % RH and dispersion solids of 15 % w/w, the calculation gives:
- Ambient moistureWater already in the air
- 11.85 g/kg
- Exhaust moistureWhat the air can hold on the way out
- 28.34 g/kg
- Dry air mass flow
- 1,743 kg/h
- Drying capacity
- 479 g/min of water
- Maximum spray rateDispersion, at the solids above
- 563 g/min
The arithmetic is 3 lines, shown beside the result above so it can be checked by hand: saturation pressure, Antoine: log10 P = 8.07131 − 1730.63 ÷ (233.426 + T); humidity ratio W = 0.622 × Pv ÷ (P − Pv); drying capacity = dry air mass flow × (W exhaust − W ambient).
Typical ranges
- Air volume(m³/h)Inlet air handling capacity
- Ambient humidity(% RH)The monsoon figure is the one that bites
- Exhaust humidity(% RH)Above about 70% the bed stops drying
These are the bands our grades were developed in at Tahliwal. A run outside them is not wrong, but it is a run the published parameters no longer describe.
